Contractor Select LED Microstrip

SKU 1ST-CSMS Category Brand:

In stock (can be backordered)

Certifications

The 1ST-CSMS Contractor Select LED Microstrip provides a compact, high-efficacy linear lighting solution for cove lighting, under-shelf applications, display cases, and general illumination where space is limited. Its slender profile and smooth diffused lens deliver even, consistent light output across a variety of mounting scenarios. This fixture is powered by a 0-10V dimmable Keystone driver and offers multiple length options for design flexibility. The microstrip design emphasizes clean aesthetics with a smooth diffused lens for a uniform appearance. It is well-suited for both new construction and retrofit projects requiring efficient, low-profile linear lighting with reliable performance and easy installation.

Commonly Purchased Together

Highlights

Slender, high-efficacy microstrip for compact and confined linear lighting.

Field Selectable

Selectable color temperature and wattage for an all-in-one solution.

Optical Distribution

120° diffused distribution for smooth linear output.

Ingress Protection

Damp location rated for covered indoor/outdoor use.

Sensor Capability

Built-in 0-10V dimming with AUX capability to power wireless controls.

Long Lifespan

>50,000 Hours rated lifespan.

Mounting Options

Chain/Cable, Surface, Pendant mounting available.

Factory Warranty

10-Year limited warranty.

Certifications

UL listed and DLC qualified.

Specifications

One SKU, Many Fixtures.

Talk to our sales team at [email protected] to match the right configuration to your application.

Photometrics

Lumen Output

3,300 to 9,900lm

Efficacy

Up to 134 lm/W

CCT Options

3500K, 4000K, 5000K

CRI

>80

Optics & Distribution

Wide, Diffused Lens

L70

>50,000 Hours

Electrical

Wattage

15w to 90w

Voltage

Universal (120-277V)

Driver

0-10V and AUX Controls Ready Driver

Power Factor

>0.95

THD

< 20%

Surge Protection

NA

Mechanical

Length

22.2″ – 94.17″

Width

2.36″

Height

2.64″

Weight

4 / 8 lbs

Housing

White housing

Mounting

Chain/Cable, Surface, Pendant

Compliance & Environment

Ingress Rating

Damp Location

Operating Temp

−4°F to 122°F (−20°C to 50°C)

Certifications

UL Listed · Damp Location · DLC

Trade Compliance

NA

Warranty

10 Year Limited

Lead Time

1-2 Weeks

Resources & Downloads

Spec packages for designers, engineers, and procurement.

PDF

1ST-CSMS Specification Sheet

IES

1ST-CSMS Photometric Files (.IES)

RFA

1ST-CSMS Revit / BIM Family

PDF

1ST-CSMS Photometric Report

PDF

1ST-CSMS Install Guide

PDF

1ST-CSMS BAA/BABA/TAA Trade Compliance
