BAY-CLHB4 · Cold Storage Linear High Bay · 4-Foot

4ft LED Cold Storage Linear High Bay

Engineered for freezers, blast cells, and cold storage

SKU BAY-CLHB4 Category

Certifications

In cold storage, lighting failure is not an option, and heat generation is the enemy. This specialized 2ft LED Cold Storage Linear High Bay provides the ultimate solution, offering immediate startup in sub-zero temperatures and high-efficiency operation that reduces the thermal load on your refrigeration systems. Offering power ranges from 85W to 300W, this fixture produces between 12,000 and 44,000 lumens of crisp, high-visibility light.

Ideal Applications

  • Industrial Walk-in Freezers and Coolers
  • Refrigerated Distribution Centers
  • Beverage Storage Facilities
  • Pharmaceutical Cold Storage
  • Unconditioned Winter Storage Facilities
85 to 300

Watts

12028 to 44771

Lumens

3500/4000/5000

Kelvin

Damp Rated

Ingress

Highlights

Engineered for the coldest freezer applications.

Cold Rated -40°F

Built to start and run reliably in freezers, refrigerated warehouses, and blast cells.

Freezer Rated Housing

Damp-rated housing protects against condensation and temperature swings.

85 to 300 Watts

12028 to 44771 delivered lumens. One housing, project-specified output.

Easy Retrofit

Direct replacement for legacy fluorescent and HID high bays.

Wireless Controls Compatible

Integrates with wireless dimming and scene control systems.

7 Year Warranty

Driver, LEDs, and housing covered.

Federal-Ready

BAA / BABA compliant for federal procurement and infrastructure.

Mounting Options

Chain/Cable, Pendant, Surface.

Specifications

Built to your project, not to a part number.

Talk to our sales team at [email protected] to match the right configuration to your application.

Photometrics

Lumen Output

12028-44771 lm

Efficacy

Up to 153 lm/W

CCT Options

3500K, 4000K, 5000K

CRI

80 (90 Available Upon Request)

Optics & Distribution

Wide, Diffused Lens

L70

>50,000 Hours

Electrical

Wattage

85 to 300 Watts

Voltage

Universal (120-277V) – 347/480V Optional

Driver

0-10V Controls Ready Standard

Power Factor

>0.90

THD

< 20%

Surge Protection

6kV/3kA

Mechanical

Length

46.2″

Width

Up to 21.9″

Height

4.5″

Weight

18.0 lbs.

Housing

Non-Vented White Aluminum

Mounting

Chain/Cable, Pendant, Surface

Compliance & Environment

Ingress Rating

Damp Rated

Operating Temp

-40ºC/−40ºF to 50ºC/122ºF

Certifications

BAA, BABA, CSA Listed, Made in the USA

Trade Compliance

BAA · BABA

Warranty

7 Years

Lead Time

4-6 Weeks

Resources & Downloads

Spec packages for designers, engineers, and procurement.

Spec’ing a project? Call us at (530) 887-1110

PDF

BAY-CLHB4 Specification Sheet

IES

BAY-CLHB4 Photometric Files (.IES)

RFA

BAY-CLHB4 Revit / BIM Family

PDF

BAY-CLHB4 Photometric Report

PDF

BAY-CLHB4 Install Guide

PDF

BAY-CLHB4 BAA/BABA/TAA Trade Compliance
