LED Direct-Indirect Indoor Pickleball Light

LED Direct-Indirect Indoor Pickleball Light
250 Watts, 38,000 Lumens, Made in The USA

(PDF) Specification Sheet

 Download IES Files

Contact Us/Request a Quote

Description

Linear LED Direct-Indirect Indoor Pickleball Light with 35%-40% indirect uplight for excellent uniformity and full court illumination. Standard mounting by unistrut with angled brackets provides maxium flexibilty for attaching to a ceiling structure. Available in 4 or 8 foot lengths.

Product Features

  • High LPW with increased efficacy
  • Direct-indrect illumination
  • Wireless control options available
  • Ant-glare diffused acrylic lens
  • Compatible with CourtReserve System
  • Service life > 100,000 hours (L90)
  • Made in the USA, BAA compliant

Applications

Designed exclisively for indoor pickleball courts.

Specifications

High flux linear LED modules, 80+ CRI, 3500K, 4000K or 5000K CCT. Constant current LED power supplies, power factor > 0.9, THD < 20%, 50-60 Hz, universal voltage 120-277v, 347v or 480v.

1st Source Lighting LED fixtures are proudly manufactured using the highest quality components such as AdvanceSylvania OsramSamsung and Tridonic.

Construction

040″ white pre-painted vented aluminum housing and LED module tray. Heavy duty .090″ angle brackets are provided for direct mount to unistrut. Linear diffused acrylic lens eliminates glare.

All fixtures are made in the USA and 100% bench tested prior to shipping.

Dimming & Control Options

Dimming to 0%, 10% or dim by line voltage. Consult factory for wireless controls options. Schedule and control lighting for your entire facility via remote switch, smartphone, PC or handheld device. Compatible with CourtReserve Tennis & Pickleball Club Management systems.

Ratings & Warranty

Operating temperature: -20ºF to 122ºF, rated service life > 100,000 hours (L90), CSA listed, BAA compliant, RoHS compliant. 5-year product warranty. Extended product warranties are available.

Lighting Layouts

1st Source Lighting also offers free lighting layouts to support your facility’s next upgrade or new construction project. Please contact us for details.
